Note: One set of calibration mats are required for setup (included). Monitor is NOT included.
Kit Contents:
OPS: 360° Control Box DVR - With Recording. Output: AHD, CBVS
X4 Cables - 5m - 20m (Please advise of your requirements - X4 20M As Standard)
X4 HD808 Slimline IP69K Cameras - 1080P
Remote Control
All Necessary Power Cables
X4 Calibration Mats
IR Extension Cable
Manual
Installation Accessories
Specifications:
OPS360 Control Box: Compact control box.
Quad-core ARM Cotex-A53 and SOC development built-in high-performance H.264 video encoding/decoding to make it efficient to composite seamless images with high accuracy.
2D & 3D Imagery Available.
Supports 2 pcs 256GB SD card for video Recording.
Max 4CH 1080P/30fps or 4CH 1080P/25fps resolution.
High definition 1080P video output.
Input Voltage: 10v - 32v
Supports Integration with pedestrian detection cameras and radar systems
User programmable interface allows for non-symmetrical vehicles (such as plant machinery) to be configured on site via laptop.
Enquire About Our Installation Services - UK Coverage.
